ENCLOSURES & JUNCTION BOXES

ENCLOSURES & JUNCTION BOXES

PRODUCT PRODUCT
INFORMATION IMAGE

SX Range - Stainless steel and Mild steel Enclosures
The SX range comprises 14 sizes of enclosure manufactured in either mild steel or stainless steel. 11 sizes
are available in depths of 140 or 200mm and 8 sizes are available in depths of 140,
200 or 300mm. The majority of the range can be fitted with removable gland plates on any or all
of the four sides. The mild steel version (MSX) is available with a number of paint options (most RAL
colours are available) and anti-corrosion finishes.
Features
• Wide Operating Temperature (- 70°C to + 175°C) (-94°F to +347°F)
• Ingress Protection up to IP68
• Fire Resistant to IEC331
• Impact Resistant > 10 Nm
• Corrosion Resistant
• Gland plates can be fitted to any or all four sides (size SX66 and above)
• Certification for use in Zone 1 and 2
• UL, CSA, IEC Ex, ATEX, FM, InMetro and GOST R and K Approvals
• Ideal for Petrochemical and Marine applications)

BPG Range - Glass Reinforced Polyester Enclosures
The BPG range comprises 16 sizes of enclosure manufactured in glass reinforced polyester
(GRP). This material is highly resistant to contamination from oils, fats, aliphatic and aromatic
carbohydrates, bacteria and enzymes. It is also suitable for LSOH (low smoke zero halogen) applications.
Polyester gives excellent mechanical strength and life expectancy. The wall thickness is
sufficient to allow tapped entry holes to be machined in the walls of the enclosure and it
provides a very good alternative to aluminium or cast iron.
Features
• Wide Operating Temperature (- 70°C to + 130°C) (-94°F to +266°F)
• Ingress Protection up to IP67
• Fire Resistant to IEC331
• Impact Resistant > 7Nm
• UV Resistant
• Can be drilled and tapped to accommodate most thread forms (NPT for example)
• Certification for use in Zone 1 and 2
• UL, CSA, IEC Ex, ATEX, InMetro and GOST R and K Approvals
• Ideal for Petrochemical and Marine applications

ZAG Range - Die-cast Aluminium Enclosures
The ZAG range of enclosures comprises of 19 different sizes of enclosures and is precision
die cast in AL-Si 12 grade (LM24) aluminium alloy. This is considered to be the most suitable grade of
aluminium for maximum corrosion resistance especially in salt laden atmospheres.
Additional optional protection methods such as alochrome, anodising and epoxy polyester
painting coupled with the fitment of captive 316 grade stainless steel lid retaining screws further enhance
the anti-corrosion properties of the enclosure.
Features
• Wide Operating Temperature (- 70ºC to +130ºC) (-94°F to +266°F)
• Ingress Protection up to IP67
• Painted and Unpainted versions
• Impact Resistant > 7 Nm
• Corrosion Resistant
• Can be drilled and tapped to accommodate most thread forms (NPT for example)
• Certification for use in Zone 1 and 2
• UL, CSA, ATEX, FM, InMetro and GOST Approvals
• Ideal for Petrochemical and Marine applications)
