Lube Filtration
Spin-on Filters by Dimension

OD Length Part Efficiency Relief Valve GSKT O.D. GSKT I.D.
Thread Item No. Description @ Primary Application Setting LUBE FILTRATION
IN MM IN MM Micron PSI Bar IN MM IN MM
M22 x 1.5 3.54 90 3.18 81 P502048 FULL FLOW 50% @ 20 HONDA 15400-PA6-305 2.52 64 2.27 58
3.64 92 5.47 139 P502072 FULL FLOW 50% @ 20 MOTORCRAFT 2.75 70
3.67 93 3.58 91 P550965 FULL FLOW 50% @ 20 FORD LIGHT TRUCK 15 1.03 2.81 71 2.42 61
3.67 93 5.42 138 P550166 FULL FLOW 99% @ 45 ONAN 122-0550 17-22 1.20-1.50 2.83 72 2.46 62
3.78 96 3.78 96 P550357 FULL FLOW FORD 844F6716AA 10-15 0.70-1.00 3.54 90 3.03 77
3.82 97 5.51 140 P553315 FULL FLOW FORD 785F-6714-AA3A 2.82 72 2.45 62
M24 x 1.5 3.66 93 5.35 136 P550758 FULL FLOW 99% @ 40 JOHN DEERE RE519626, RE518977 24 1.70 2.83 72 2.44 62
3.75 95 6.88 175 P550975 FULL FLOW VALMET 836136342 34-37 2.40-2.60
M26 x 1.5 3.54 90 4.92 125 P502043 COMBINATION 50% @ 20 ISUZU 8943604271 3.44 87 3.00 76
3.58 91 4.92 125 P502058 COMBINATION 50% @ 20 DAIHATSU, ISUZU, MAZDA 3.43 87 3.00 76
3.66 93 6.92 176 P557382 COMBINATION 99% @ 25 THERMO KING 117382, 2.81 71 2.42 61
M27 x 2 3.85 98 6.89 175 P550520 FULL FLOW DAF 1399494 2.83 72 2.44 62
M92 x 3.66 93 5.94 151 P550779 FULL FLOW 99% @ 40 JOHN DEERE RE504836
2.5-6H

100 mm / 3.94”Dia. Family
1-12 3.96 101 4.92 125 P502060 FULL FLOW 50% @ 20 MAZDA TFY014302 11-17 0.80-1.00 3.92 100 3.48 88
3.96 101 4.92 125 P550411 FULL FLOW MAZDA 130523802 11-17 0.80-1.00 3.92 100 3.48 88
3.98 101 5.85 149 P505956 FULL FLOW HINO
4.02 102 5.91 150 P550409 FULL FLOW 50% @ 16 MAZDA SL0223802 3.92 100 3.46 88
4.02 102 5.91 150 P502080 FULL FLOW 50% @ 20 MITSUBISHI 32B4000100 3.91 99 3.46 88
4.00 102 5.92 150 P550422 FULL FLOW HITACHI 4183853, ISUZU 8943212191 17 1.20 3.92 100 3.48 88
M24 x 1.5 3.93 100 3.30 84 P502017 COMBINATION 50% @ 5 TOYOTA 90915-03003, 90915-30001 11-17 0.80-1.00 3.15 80
M26 x 1.5 4.02 102 4.92 125 P502061 COMBINATION MAZDA VSY114302 3.35 85 2.17 55
4.02 102 5.31 135 P551343 BYPASS 50% @ 16 MITSUBISHI MD069782 12-16 0.80-1.00 2.87 73 1.77 45
4.02 102 6.02 153 P550406 FULL FLOW 50% @ 16 HINO 156071480 11-17 0.80-1.00 2.87 73 2.20 56

108 mm / 4.25”Dia. Family
1-12 4.21 107 3.96 101 P502085 FULL FLOW 50% @ 20 MITSUBISHI 32A4000100 18-24 1.30-1.70 3.90 99 3.46 88
4.25 108 5.14 131 P502032 COMBINATION 50% @ 20 ISUZU 8941432050 2.90 74 2.15 55
4.23 107 5.79 147 P559126 FULL FLOW 99% @ 40 FORD E7HZ6731A (BRAZIALIAN CAB FORWARD) 18-23 1.30-1.60 2.82 72 2.42 61
4.25 108 6.61 168 P553871 FULL FLOW 50% @ 20 THERMOKING 11.3871 2.82 72 2.42 61
4.27 108 8.00 203 P550319 FULL FLOW 99% @ 25 IHC 1811953C1 FOR DT/DTA360 & 466 DIESEL 2.82 72 2.42 61
ENG
4.27 108 9.09 231 P550393 FULL FLOW 99% @ 40 MERCEDES TRUCK 0031841701 2.82 72 2.44 62
4.25 108 9.13 232 P551604 FULL FLOW 50% @ 14 FIAT 71909137, IVECO 01901604 18-20 1.30-1.40 2.81 71 2.46 62
1-16 4.28 109 5.78 147 P550152 FULL FLOW 99% @ 40 FIAT ALLIS, A.CHALMERS 4023548-3 2.83 72 2.45 62
4.28 109 7.33 186 P552474 FULL FLOW Allis Chalmers 4037047 2.83 72 2.46 63
7/8-16 4.27 108 8.06 205 P550714 FULL FLOW 99% @ 40 WHITE 30-3068145 18-25 1.30-1.70 2.82 72
4.23 108 7.95 202 P559130 FULL FLOW 99% @ 40 CaseIH A62423 2.83 72 2.44 62
3/4-16 4.24 108 6.59 167 P551267 FULL FLOW 99% @ 30 NISSAN 15201Z9008 2.82 72 2.46 62
4.26 108 7.25 184 P551603 FULL FLOW 99% @ 23 FIAT 71909101, IVECO 01901603, HESSTON 30 2.07 2.83 72 2.44 62
4.28 109 3.77 96 P550580 FULL FLOW 99% @ 45 FORD, MASSEY FERGUSON, MPLS MOLINE 8-11 0.60-0.80 2.81 71 2.42 61
4.40 112 5.70 145 P550226 FULL FLOW 50% @ 4 IVECO 1902047 20-23 1.30-1.80 2.83 72 2.44 62
3/4-20 4.28 109 7.89 200 P553746 BYPASS 99% @ 12 THERMO KING 11.3746 2.83 72 2.45 62
1 1/2-12 4.25 108 10.42 265 P502081 FULL FLOW 50% @ 16 MITSUBISHI 3754001101 4.02 102 3.42 87
1-1/2–16 4.23 107 5.79 147 P559127 FULL FLOW 99% @ 40 FORD E3TZ6731A, IHC 6.9L 1804442C1 3.89 99 3.55 90
4.27 108 8.02 204 P550371 FULL FLOW 99% @ 25 NAVISTAR 1822731C1, 1814562C1 Ford 3.89 99 3.55 90
F4TZ-6731-A

www.donaldson.com Engine Liquid Filtration • 83
