Scalers

Accessories

For RRC13, 13B, P2505 For RRC13N Needle-set of 19 needles, length 100 mm

RRC13 / RRC13B Ordering No. Material Ordering No.
RRC13 / RRC13B Steel, standard 3510 0221 90
Hand guard 3510 0246 90 Steel flat ends 3510 0227 90
Stainless steel flat ends 3510 0228 90
P2505 Beryllium copper flat ends 3510 0229 90
(spark resistant)
Needle and small parts kit 4081 0068 90

Chisels for RRC13/13B, square shank 13.0 mm
Square

Width Length 13 mm (1/2")
Chisel type Designation mm in mm in Ordering No.
Chisel blank 15 0.59 155 6.1 3085 0020 00
15 0.59 200 7.9 3085 0020 01
15 0.59 300 11.8 3085 0020 02
Flat chisel 15 0.59 165 6.1 3085 0227 00
15 0.59 200 7.9 3085 0227 01

Wide flat chisel 35 1.38 165 6.5 3085 0032 00
35 1.38 200 7.9 3085 0032 01
35 1.38 300 11.8 3085 0032 02
55 2.17 165 6.5 3085 0332 00

Angle scraper 35 1.38 165 6.5 3085 0176 00
chisel 35 1.38 200 7.9 3085 0176 01
55 2.17 165 6.5 3085 0333 00

Scaling chisel 15 0.59 155 6.1 3085 0018 00
15 0.59 200 7.9 3085 0018 02
15 0.59 300 11.8 3085 0018 01

Chisels for RVM07B, special shank
Width Length
Chisel type Designation Material mm in mm in Ordering No.

Flat chisel Tungsten carbide 10 0.39 120 4.7 3085 0321 00
Through hardened steel 10 0.39 120 4.7 3085 0325 00
Tungsten carbide 10 0.39 200 7.9 3085 0321 01
Tungsten carbide 10 0.39 300 11.8 3085 0321 02
Tungsten carbide 20 0.79 120 4.7 3085 0345 00
Through hardened steel 20 0.79 120 4.9 3085 0346 00
Wide chisel Tungsten carbide 35 1.38 120 4.7 3085 0322 00
Through hardened steel 35 1.38 120 4.7 3085 0327 00

Productivity Kits

Model Economical air flow Hose Coupling Lubrication Ordering No.
For percussive tools with 3/8" BSP air inlet incl. whip hose
MIDI Optimizer F/RD EQ10-R13-W 21 l/s Rubair 13 mm ErgoQIC 10 Yes 8202 0850 14
For percussive tools incl whip hose, no tool nipple included
MIDI Optimizer F/RD EQ10-R13-W 21 l/s Rubair 13 mm ErgoQIC 10 Yes 8202 0850 15

Material removal tools 57
